Dimensions
Min Size: Minimum door width of 34" (864mm)
Max Size: Custom Sizes up to 60" W x 96" (1524mm x 2440mm) per door
Max Weight: 440lb (200kg) per door
Wall Framing: 3½" or 3⅝" (90mm) or 5½" (140mm)
Suitable Door Types
Can be specified with almost any choice of door that meets a minimum door width of 34” (860mm) and a maximum door width of 60” (1524mm).
Design & Safety Features
• Self-tensioning pulley and heavy duty belt.
• Carriages with nylon wheels and enclosed bearing races for smooth, maintenance free operation.
• Safety beam sensors provide obstacle detection.
• Access points in the head unit ensure access to the track section.
• Fully programmable controller with many standard operating modes. Includes built in safety beam controller, object detection and smart learning modes.
Configurations
Available in Single and Bi-Parting (Double Door) Configurations
Access Control Options
A variety of access control options are available, from simple push button or overhead sensor to secure entry via touch pad, swipe key or a combination of methods.
In the event of power failure, the door can be manually opened or a battery backup can be supplied, for example:
- Handwave Sensor
- Standard Light Switch
- Dry Wire to connect to 3rd party smart home or building management system
- Heavy Duty Push Button Access
- Piezo Button
- Overhead Sensor
