Features
This detail requires nomination of a lead door, as one edge will typically butt into the face of another.
All CornerMeeting dimensions must be confirmed by a CAD Drawing
A variety of configurations available, including multi-track systems meeting a single or multi track.
Technical Details
We recommend the use of CS NewYorker or CS AluTec doors when using this detail (90˚) for the following reasons:
• Aluminium door leaves are straight, ensuring a neat overlap join when tracks are installed.
• Magnets can be hidden within the aluminium door stiles for a positive closing action.
